2 What it does The Surtronic Duo is superior portable surface roughness tester that measure multiple roughness parameters with a 1-button click. Roughness measurement parameters such as Ra, Rz, Rp, Rv and Rt are displayed on a brightly lit intuitive 2.4' LCD colour display.
Its rechargeable battery operation makes it a convenient way of performing fast, easy and precise on-the-spot measurements in almost any environment and surface. How it does it The hard-wearing diamond stylus is drawn across the part with a precision motorised traverse mechanism to ensure that the correct horizontal distance is travelled.
Vertical movement of the stylus is detected by a high quality piezo-electric pick-up as it travels across peaks and valleys which converts mechanical movement into electrical signals. The electrical signal is digitised and sent to a microprocessor for instant calculation of surface parameters using standardised algorithms. Surtronic Duo Measure Tactile measurement button great for challenging orientations Bluetooth technology Quick, reliable communication between traverse and display/ control unit. Separates The Duo splits into a display/control unit and traverse unit via a slide and lock mechanism.
USB Mini charging The mini USB port can be used for charging with the included mains charger (or with any standard USB charger). Diamond stylus and piezoelectric pick-up The hard wearing, robust piezoelectric pick-up stylus with diamond tip assures very reliable measurement.
Surtronic 3+ Manual
Li-Poly battery Most advanced rechargeable battery technology for unrivalled reliability and battery life. 3 Keeping it simple Profile graph Clear detailed graph showing measurement area excellent for visually identifying defects. Simple 3-button navigation Instant access to menu options and settings. The Surtronic philosophy keeps the process simple. It is the perfect tool for any inspector to check surface roughness even in the most demanding applications. Incoming inspections Final inspection before shipment Process control on the production line Checking large components or structures Standards and traceability The reference standard supplied can be used both to calibrate the instrument and check for stylus wear to ensure the most accurate results are always being achieved. Measurement Roughness standards (Ra) Workpiece or component surface texture (Ra) Best capability ±(2% µm) ±3% of measured value per trace UKAS calibration and testing Taylor Hobson provides full certification for artefacts and instruments in our purpose built ISO graded clean room UKAS facility.
Our UKAS laboratory is able to measure all of the parameters associated with surface texture, including French, German, USA and Japanese derivatives. USB mini charging port Charge from mains or any standard USB charging port Rubberised moulding Enhanced durability and improved grip provides unbeatable protection in harsh shop floor environments. 4 Tough, fast and reliable handheld roughness testers Durable roughness testers for shop floor, industrial & inspection room applications Fast and reliable Simply press the measurement button and in a few seconds a full set of traceable measurement results including a detailed profile graph is displayed. Built to last, by design Impact resistant rubberised mouldings surround a recessed, Mylar protected high durability screen making the unit robust enough for even the most demanding industrial environments.
InstantOn By utilising InstantOn technology these instruments are ready to measure in less than 5 seconds from switching on! In situ measurements Monitor wear and roughness changes in situ during product s life. Monitoring changes in turbine blade roughness as an early warning sign for defects and efficiency losses. User-friendly, not user-hostile! The Surtronic Duo are as simple and easy-to-use as any SmartPhone.
Surtronic Duo Manual
Users have the advantage of the intuitive quick access 3-button menu and its crisp 2.4' daylight readable industrial colour LCD screen Bluetooth connectivity This next generation bluetooth technology boasts super efficient connectivity allowing wireless communication between the display unit and traverse unit. Built for power Powered by heavy duty reliable Li-Poly technology, the Surtronic Duo operates 24/7 with over 2000 measurements from a single charge. Parameters available: ISO 4287 Roughness.
Surtronic Duo Surface Roughness Tester
Rt total profile height Rp maximum profile peak height Rv maximum profile valley depth Rz maximum height of the profile Ra arithmetic mean deviation Other parameters include: Rsk, Rku, Rq, Rz1max. Includes primary parameters 4.
5 Applications Grinding Glass and construction Sheet steel Milling Aerospace Honing Turning Turbines Flooring and many more. 10 Accessories and spares 1 Portable hybrid solar rechargeable power bank. Portable power bank for charging the Surtronic Duo on the go. Can be charged by USB, mains AC or sunlight. 2 Compact portable carry bag Helps secure the Surtronic Duo and prevent accidental drops especially for applications involving measuring at heights. Code SA-51 Code SC-15 3 USB charger Mini USB charger 5V 1A VAC 50/60 Hz with international adapters Code SC-10 4 Hard transport case.
Air and water tight case that provides the Surtronic Duo with extra protection for safe storage and/or transportation. Code SA-55 5 Calibration standard For calibrating and checking the Surtronic Duo instrument. Code CS-20 Ra 5.81 μm (229 μin) 6 Magnetic base.
Lightweight compact base specially designed to allow for measurements in multiple orientations including upside down on metallic surfaces. Code SA-41.
Avery e1105 service manual. Not supplied as standard with Surtronic Duo All accessories listed above are available for order. Please contact your local Taylor Hobson representative for additional or special requirements.
Now in stock – Buy now The Surtronic Duo surface roughness tester is normally available ex-stock for immediate despatch. To place an order - credit card orders welcome.
